Wireless HDMI® 60 GHz indoor solution

Small size, low power consumption and high cost effectiveness solution

Wireless HDMI® IN-ROOM VIDEO

60 HZ Wireless video free from interface

Wireless HDMI®

1080p/60Hz

maximum video resolution

Wireless HDMI® 4K

1080p/120Hz

maximum video resolution

4K30

used with SiI9396 HDMI bridge device

Average 5 ms video latency

WirelessHD® v1.1 compliant

Surround sound audio

CEC or AVC commands

Ideal for real time video

HDCP content protection

Wireless HDMI® Module
Wireless HD® TRANSMITTER MODULE

MOD6320-T

The MOD6320-T/MOD6320-4K-T is a WirelessHD® module for highly integrated video source devices and transmitter adapters built with SiBEAM® technology. The transmitter module provides a digital audio/video interface compatible with HDMI®, enabling wireless transmission of high quality video to any WirelessHD-compliant receiver. WirelessHD® effectively eliminates unsightly cable installation, while maintaining the same visual quality and reliability.

Industry-Standard Compliance
WirelessHD® Specification v1.1 HDMI 1.4b / 2.0 HDCP 1.4 / 2.2
Digital Input/Output
HDMI USB for debug I2C for advanced control
Module Dimensions
74 mm x 17 mm x 5.4 mm Cable length 30 mm
Wireless Range
Up to 10 m in-room
Operating Frequency
59.40 GHz to 63.72 GHz Channels 2 and 3
Operating Temperature
0 to 60 °C ambient temperature
Modular Regulatory Approval
IC (Canada) SRRC (China) ETSI (EU) KCC (Korea) TELEC (Japan) FCC (USA)
Wireless HD® RECEIVER MODULE

MOD6321-R

The MOD6321-R/MOD6321-4K-R is a WirelessHD® module for highly integrated display devices and receiver adapters built with SiBEAM® technology. The receiver module provides a digital audio/video interface compatible with HDMI®, which allows reception of high quality video from any WirelessHD®-compliant transmitter. WirelessHD® effectively eliminates unsightly cable installation, while maintaining the same visual quality and reliability.

Industry-Standard Compliance
WirelessHD® Specification v1.1 HDMI 1.4b / 2.0 HDCP 1.4 / 2.2
Digital Input/Output
HDMI USB for debug I2C for advanced control
Module Dimensions
74 mm x 17 mm x 5.4 mm Cable length 30 mm
Wireless Range
Up to 10 m in-room
Operating Frequency
59.40 GHz to 63.72 GHz Channels 2 and 3
Operating Temperature
0 to 60 °C ambient temperature
Modular Regulatory Approval
IC (Canada) SRRC (China) ETSI (EU) KCC (Korea) TELEC (Japan) FCC (USA)
Wireless HDMI® Chipset
SiI6320 Wireless HDMI® TRANMITTER NETWORK PROCESSOR

Sil6320

The SiI6320 network processor is a WirelessHD™ 1.1 compatible network processor that provides a complete wireless video-area network (WVAN) solution. The SiI6320 processor, when combined with the SiI6310 RF transceiver, provides all of the functionality needed to enable a complete wireless A/V network, from joining an existing network to joining a WVAN as a station. Full support for AVC commands, compatible with HDMI-CEC, is provided.

Specifications and features

HRP channels 2 and 3 at up to 4.0 Gb/s (mode index 0, 1, 2, 7, 8, and 9)

MRP mode index 0, 1, 7, and 8 transmission at up to 1.2 Gb/s

WirelessHD compatible

Receives back-channel audio over LRP

Small form factor 153 pad 13 x 13 mm aQFN package

High quality transmission at up to 10 -9 BER

Hollywood-approved content protection using HDCP encryption

Embedded CPU manages WirelessHD WVAN protocol Software compatible with Silicon Image Wireless SDK

Omni and directional LRP modes at up to 10.0 Mb/s

Support for video resolutions from 480i/576i to 1080p/60 Hz

Integrated HDMI/DVI interface

Support for 2–8 channel audio up to 192 kHz

Full support of AVC commands

WirelessHD Coordinator capable

Integrated HDMI 1.4b compatible Audio Return Channel

Lossless video coding and gated transfer for improved performance and QoS

SiI6310 Wireless HD® RF Transceiver

Sil6310

The SiI6310 WirelessHD RF Transceiver supports the WirelessHD 1.1 Standard. When combined with the SiI6320 and SiI6321 network processors, it provides a complete solution for enabling a Wireless Video-Audio Network (WVAN). No system firmware support is needed for the SiI6310 RF transceiver because the SiI6320/21 processors manage all aspects of the WirelessHD protocol, including the beamsteering algorithms. Innovative micro array antenna technology simplifies the RF design by embedding the antenna array in the device package.

Specifications and features

4 Gb/s data transfer rate

High efficiency PA and LNA components

No routing of 60 GHz signals to PCB board

On-package antenna eliminates the need for RF antenna design

Low-pin count interface to the SiI6320 and SiI6321 network processors

Supports omni and directional LRP modes at up to 10 Mb/s

WirelessHD 1.1 Specification Compliant

HRP Channel index 2 or 3 capable

Embedded beam forming technology

Transmits uncompressed Deep Color 1080p/60 Hz 4:4:4 36 bit video

Low cost, 12 mm x 12 mm organic flip chip 76 ball BGA package with embedded antenna array

Supports MRP and five LRP channels per HRP channel

SiI6320 Wireless HD® RECEIVER NETWORK PROCESSOR

Sil6321

The SiI6321 WirelessHD Receiver Network Processor is a third generation, WirelessHD 1.1-compatible, network processor that provides a complete wireless video area network (WVAN) solution. The SiI6321 processor, when combined with the SiI6310 RF transceiver, provides all of the functionality needed to enable a complete wireless A/V network, including starting its own WVAN as a coordinator. Full support for AVC commands, compatible with HDMI CEC, is Provided.

Specifications and features

HRP channels 2 and 3 at up to 4.0 Gb/s (mode index 0, 1, 2, 7, 8, and 9)

MRP mode index 0, 1, 7, 8 reception at up to 1.2 Gb/s for uncompressed or coded A/V

WirelessHD1.1 compatible

Transmits back-channel audio over LRP

Omni and directional LRP modes at up to 10.0 Mb/s

High quality transmission at up to 10 -9 BER

Hollywood-approved content protection using HDCP encryption

HDCP keys pre-programmed for highest level of protection and ease of design

Embedded CPU manages WirelessHD protocol, thereby simplifying host interaction; handles all aspects of creating, joining, or leaving WVAN

Small form factor 154 pad 14 mm x 14 mm advanced QFN (aQFN) package

Support for video resolutions from 480i/576i to 1080p/60 Hz

Integrated HDMI/DVI interface

Support for 2–8 channel audio up to 32-192 kHz

Full support of AVC commands

WirelessHD Coordinator capable

Integrated HDMI 1.4b compatible Audio Return Channel

Lossless compression and full-frame buffer for improved wireless performance

SiI6312 Wireless HD® RF RECEIVER

Sil6312

The SiI6312 WirelessHD RF Receiver supports the WirelessHD 1.1 Standard. When combined with the SiI6321 network processor, it provides a complete A/V Receiver solution for enabling a Wireless Videoaudio Network (WVAN). Simultaneous orthogonal antenna elements are oriented to provide optimum RF link integrity with WirelessHD transmitters regardless of planar orientation.

Specifications and features

HRP Channel index 2 or 3 capable

Supports MRP and five LRP channels per HRP channel

Receives 1080p @ 60 Hz video support

No routing of 60 GHz signals to PCB board

On-package antenna eliminates the need for RF antenna design

Low-pin count interface to the SiI6320 and SiI6321 network processors

WirelessHD 1.1 Specification Compliant

4 Gb/s data transfer rate

High efficiency PA and LNA components

Embedded beam forming technology

Supports omni and directional LRP modes at up to 10 Mb/s

Low cost, 12 mm x 12 mm organic flip chip 76 ball BGA package with embedded antenna array
